1898 Window Series
All-Clad Single-Hung
Rivertown Window’s 1898 Window Series is the culmination of decades of experience building windows for structures built at the turn of the last century. The window features a 1-11/16" sash thickness, which was commonly used in windows of this era. This single-hung window features a 7/8" insulated glass unit (IGU), which allows for better insulating properties and more Argon gas (when specified) than our previous window design. For the balance system, we partnered with America’s oldest spring manufacturer to integrate a concealed-balance system that preserves the historically accurate sight lines of the window.
TECHNICAL SPECIFICATIONS
-
Shapes available include:
Rectangular
Arched
Half-Round
EllipticalStandard window sizes:
Minimum: 2’ x 3’
Maximum: 5’ x 10’Larger custom window units available upon request and engineering review.
-
-
100% Wood (Ponderosa Pine or Sapele) OR with Aluminum-Clad Exterior.
-
-
7/8” Glass
7/8" Insulated Glass
Low-E (most energy efficient option)
Clear (most historically-accurate option)
Argon available upon request
-
Concealed constant force balance system preserves the historical sight lines that are important to discerning property owners, historical preservation boards, and state historic preservation offices (SHPOs).
Balance system meets AAMA 902-24 specifications.
-
Sloped sill to aid water run-off
-
2 3/8” Top Rail
2 3/8” Stiles
1 5/8” Check Rail
3 5/16” Bottom Rail
1 11/16” Thick Sash
Sash can also be supplied loose for an existing historic window frame. In those instances, sides of the sash will be fabricated to accept the existing sash rope or chain. Requires ± 1 3/4” sash pocket.
-
Robust 3/4" × 5-9/16" Jamb
-
Oil-Rubbed Bronze Hardware (Lock, Keeper, and Lift Handle)
-
Single-Hung window
Top sash fixed
Bottom sash operates
-
Primed and custom colors available upon request.
